| The New Light Duty Racking | |||
|---|---|---|---|
| Loading Capacity (kg) | Shelf Thickness | Upright Thickness | Beam Thickness |
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel |
| The New Medium Duty Racking | |||
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel |
| Size (cm) | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity (kg) |
|---|---|---|---|
| Thicken 200*60*200=4 layers | 44±0.5 | 40±0.5 | 180kg/layer |
| Thicken 200*50*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer |
| Thicken 200*40*200=4 layers | 39±0.5 | 35±0.5 | 180kg/layer |
| Thicken 180*60*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer |
| Thicken 150*60*200=4 layers | 37±0.5 | 32±0.5 | 180kg/layer |
| Thicken 150*50*200=4 layers | 33±0.5 | 28±0.5 | 180kg/layer |
| Thicken 150*40*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer |
| Thicken 120*60*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer |
| Thicken 120*50*200=4 layers | 27±0.5 | 23±0.5 | 180kg/layer |
| Thicken 120*40*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer |
| Thicken 100*50*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer |
| Thicken 100*40*200=4 layers | 23±0.5 | 19±0.5 | 180kg/layer |
| The New 200*50*200=4 layers | 33±0.5 | 29±0.5 | 120kg/layer |
| The New 150*50*200=4 layers | 27±0.5 | 23±0.5 | 120kg/layer |
| The New 150*40*200=4 layers | 25±0.5 | 21±0.5 | 120kg/layer |
| The New 120*50*200=4 layers | 24±0.5 | 20±0.5 | 120kg/layer |
| The New 120*40*200=4 layers | 21±0.5 | 18±0.5 | 120kg/layer |
| The New Medium 200*60*200=4 layers | 49±0.5 | 42±0.5 | 240kg/layer |
| The New Medium 200*50*200=4 layers | 44±0.5 | 38±0.5 | 240kg/layer |
| The New Medium 150*60*200=4 layers | 41±0.5 | 34±0.5 | 240kg/layer |
| The New Medium 150*50*200=4 layers | 37±0.5 | 30±0.5 | 240kg/layer |
| Item | Value |
|---|---|
| Material | Steel |
| Feature | Corrosion Protection |
| Type | Boltless / Rivet Shelving, Selective Pallet Rack |
| Length of layers | L1200/1500 |
| Layer | 5 Layer, 1 Layer, 2 layer, 3 layer, 4 layer, 8 Layers |
| Surface Treatment | Powder coated |
| Installation | Industrial Shelving |
| Model Number | LSR001 |
| Special Feature | Adjustable |
1. Who are we?
We are a professional racking manufacturer established in 2008. We distribute our products across several markets, including Domestic Markets (88.00%), Western Europe (5.00%), Central America (3.00%), South America (2.00%), Eastern Asia (1.00%), and Africa (1.00%). Our head office operations include a strong dedicated team of professionals.
2. How can we guarantee quality?
Quality is consistently maintained by providing a pre-production sample before launching mass production, along with conducting a rigorous final inspection on all units prior to shipment.
3. What products can you purchase from us?
We supply a wide range of products including Warehouse Storage Racks, Pallet Racks, Cantilever Racking, Supermarket Racks, and Household Shelves.
4. Why choose us over other suppliers?
With over 25 years of design and development experience, our creative solutions and professional design expertise enable us to configure and customize shelving systems to meet any customer's specific requirements.
5. What services do we offer?
We support accepted delivery terms including FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, and DES. Transaction currencies accepted include USD and CNY through multiple payment options like T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, and Escrow. We provide services in English and Chinese.
6. What surface protection do the racks have?
All storage racks are treated with an eco-friendly powder-coated spray finish to guarantee effective corrosion protection and structural durability under various load environments.
