Shibang Rack
1 / 5
| Size (cm) | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity (kg) |
|---|---|---|---|
| 200*60*200 = 4 layers | 72 ± 1 | 63 ± 0.5 | 400kg/layer |
| 200*50*200 = 4 layers | 68 ± 1 | 59 ± 0.5 | 400kg/layer |
| 150*60*200 = 4 layers | 59 ± 1 | 50 ± 0.5 | 400kg/layer |
| 150*50*200 = 4 layers | 56 ± 1 | 47 ± 0.5 | 400kg/layer |
| 120*60*200 = 4 layers | 51 ± 1 | 42 ± 0.5 | 400kg/layer |
| 120*50*200 = 4 layers | 49 ± 1 | 39 ± 0.5 | 400kg/layer |
| Material Description | Specification Specifications |
|---|---|
| National standard upright thickness | 40*80*1.2mm C steel |
| National standard beam thickness | 40*60*1.2mm P steel |
| National standard shelf thickness | 0.5mm thick cold rolled steel sheet |
| Item | Value |
|---|---|
| Layer | 4, 1 Layer, 2 layer, 3 layer, 5 Layer |
| Material | Steel |
| Type | Multi-Level |
| Feature | Adjustable, Heavy Duty |
| Installation | Freestanding |
| Surface Treatment | Electrostatic powder coating |
| Length of layers | 200cm |
| Main sub rack form | main sub |
| Main sub structure | main frame |
| Rack accessories | Pallet support bar, screw bracket, Shell and Tube |
| Usage | Warehouse Storage System |
| Color | Blue |
| Application | Goods Storage |
| Packing | Customers' Request |
| Function | Large Load Capacity Warehouse Storage |
| Certification | CE/ISO9001 |
| OEM&ODM | Acceptable |
| Advantages | Professional Design and Industry Experience |
1. What materials are used to construct these heavy duty racking systems?
Our racks are manufactured using high-quality national standard steel. The standard specifications include 40*80*1.2mm C steel for the uprights, 40*60*1.2mm P steel for the beams, and a 0.5mm thick cold rolled steel sheet for the shelves, ensuring optimal durability and safety.
2. What is the standard weight loading capacity per layer?
The standard loading capacity is 400kg per layer. However, loading limits can be customized and constructed based on specific heavy-duty or custom requirements.
3. Can we customize the dimensions, colors, and layers?
Yes, both OEM and ODM orders are welcome. We offer options ranging from 1 to 5 layers, customized dimensions (standard sizes include length of 200cm, 150cm, and 120cm with depths of 50cm or 60cm), and color selections in Blue, White, or Orange.
4. How is the surface of the steel protected against corrosion?
All structural steel components undergo electrostatic powder coating. This clean, environmental protection spray treatment ensures durable corrosion and rust resistance.
5. What quality certifications do these storage systems have?
Our manufacturing processes and warehouse racking products are fully compliant with CE and ISO9001 certifications to guarantee strict quality and safety control.
6. What parts and accessories are included in a standard system purchase?
A standard set consists of main frame and sub frame components, including pallet support bars, screw brackets, shell and tube connectors, and all necessary mounting hardware.
