Shibang Rack
1 / 5
| Size (cm) | Style | Weight (kg) | Frame Type | Dead Weight (±1kg) | Loading Capacity (kg/layer) |
|---|---|---|---|---|---|
| 120*60*200 = 4 layers (Spot blue, white. Gray, orange custom) |
2 Uprights | 5.3 | Body-frame | 65.7 | 600 |
| 8 Beams | 25.2 | Sub-frame | 55.1 | ||
| 8 Shelves | 35.2 | - | - | ||
| 150*50*200 = 4 layers (Spot blue, white. Gray, orange custom) |
2 Uprights | 20.2 | Body-frame | 69.9 | 600 |
| 8 Beams | 29.92 | Sub-frame | 59.8 | ||
| 8 Shelves | 20.48 | - | - | ||
| 150*60*200 = 4 layers (Spot blue, white. Gray, orange custom) |
2 Uprights | 21.2 | Body-frame | 73.7 | 600 |
| 8 Beams | 29.92 | Sub-frame | 63.1 | ||
| 8 Shelves | 22.56 | - | - | ||
| 200*50*200 = 4 layers (Spot blue, white. Gray, orange custom) |
2 Uprights | 20.2 | Body-frame | 85.4 | 600 |
| 8 Beams | 39.2 | Sub-frame | 75.3 | ||
| 8 Shelves | 26 | - | - | ||
| 200*60*200 = 4 layers (Spot blue, white. Gray, orange custom) |
2 Uprights | 21.2 | Body-frame | 92.1 | 600 |
| 8 Beams | 39.2 | Sub-frame | 81.4 | ||
| 8 Shelves | 31.6 | - | - |
| Material Description | |
|---|---|
| National standard upright | 40*80*1.5mm C steel |
| National standard beam | 40*60*1.5mm P steel |
| National standard shelf | 0.6mm thick cold rolled steel sheet |
